Bently Nevada 330380-90-00 3300 XL 16mm High Temperature Proximitor Sensor

Contact info

Email:sales3@askplc.com

Mobile:86-18150117685

Website:https://www.controldcs.com/

Manager:John Yang in moore automation

Item Overview

Gas and steam turbines can produce temperatures hot enough to damage or destroy conventional proximity probes. The 3300 High Temperature Proximity System (HTPS) is designed to withstand the extreme temperatures found inside gas turbines, steam turbines and other types of rotating machinery. The HTPS measures vibration, thrust position, differential expansion and other parameters inside the hot areas of these machines. High temperature installations include:
Near a labyrinth seal in steam turbines，
Differential expansion in steam turbines，
When probe cables are routed through struts that support the bearing housing of a gas turbine，
When probe cables are routed out through the exhaust path of a gas turbine，
Monitoring a troublesome bearing in a high temperature area，
Mode shape analysis at the mid-span location on steam and gas turbines for online machinery diagnostics，
Interstage radial and axial seal clearance measurements at the mid-span location of multistage steam turbines to minimize seal rubs，
Most hot bearing locations that can destroy conventional proximity probes.

Performance Specifications

Product Type:

3300 XL 16mm High Temperature Proximitor Sensor

Total Length / Mounting:

9 m, panel mount

Agency Approval:

Not required

Input:

Accepts one non-contacting 3300 XL HTPS 16 mm Proximity Probe with matched extension cable

Power Requirements:

-19.6 V DC to -26 V DC, max 12 mA

Voltage Sensitivity:

<13 mV change per volt change in input voltage

Output Resistance:

50 Ω

Sensor Material:

Aluminum with epoxy powder coat finish

Operating Temperature:

-52°C to +100°C

Storage Temperature:

-52°C to +105°C

Probe Relative Humidity:

100% condensing; submersible if connectors protected

FAQ

Question

Answer

Q: What is the 330380-90-00?

A: It is a 3300 XL 16mm High Temperature Proximitor Sensor.

Q: What shipping methods are used for 330380-90-00?

A: Major carriers like FedEx, DHL, and UPS are primarily used for worldwide delivery.

Q: How are the 330380-90-00 packaged?

A: 330380-90-00 packaging generally involves multiple layers of protection to ensure safe transit.

Q: How to Check Price and Availability for 330380-90-00?

A: Please contact John Yang for sales at +86-18150117685 or request a quote.

Q: How long is the warranty period of 330380-90-00?

A: We offer a standard one-year warranty for all new and original products.
