WARTSILA ACM-20 Four-Function AC Power Meters

For brand new, original automation products at great prices, contact Sales Manager John Yang. He's available 24/7. For more information, please contact:

Long Description

Murata Power Solutions’ ACM20 series AC power meters display the most critical measurements in mains-powered equipment: voltage, amperage, active power (watts), and power factor. A front panel selector-switch provides two modes of operation: a fixed reading of any of the four parameters, or a continuous cycling through all four measurements. An optional model displays line frequency with 0.1Hz resolution. All ACM20 multi-function power meters include built-in current transformers—no other user-supplied components are required. ACM20 series AC power meters are available in a choice of three input ranges: 0-10A (with 0.001A resolution, 999.9 watts max.); 0-32A (with 0.01A resolution, 9999 watts max.); and 0-100A (0.1A resolution, 26.4kW max.). An 85-264Vac (47-63Hz) operating supply range makes these power meters perfect for worldwide power monitoring applications. And, unlike conventional, average-responding products, ACM20 power meters can accurately display the real power and true-rms current values of triangle waves, square waves, and other irregularly shaped waveforms, with a typical accuracy of ±1% of full scale.

Technical Details

Dimensions: 7.4×14.2×19.8 cm
Weight: 0.38 kg
Sampling Rate: 2–3 samples/sec
Voltage Accuracy: ±1%
Current Accuracy: ±1%
Power Accuracy: ±2%
Frequency Accuracy: ±0.1 Hz
Power Factor Accuracy: ±3%
Measurement Bandwidth: 140 Hz (Voltage), 14 kHz (Current)
Temperature Drift (0–60°C): 0.5 Counts/°C
Zero-Current Reading (within 2 sec): 0.00 Amps
Zero-Power Reading (within 2 sec): 0 Watts
Measurement Category: UL/IEC61010-1 CAT II
Overcurrent Rating: 1.5× rated full-scale current
Wire Size: 16–22 AWG, solid or stranded
Insulation Strip Length: 6.4 mm (0.250 in)
Screw Tightening Torque: 0.4 N·m (3.6 lb-in)
Rated Voltage: 300 VAC
Display Type & Size: 4-digit LED, 9.14 mm (0.36 in) high
Overrange Indication: Flashing ‘9999’ Watts
Decimal Point Selection: Automatically Set
Operating Temperature: 0–+60 °C
Storage Temperature: −40–+75 °C
Humidity (non-condensing): 0–85 %
Weight (32A model): 1.3 oz (37.9 g)
Weight (100A model): 1.5 oz (43.5 g)
Hex Nut Tightening Torque: 0.14 N·m (20 ozf-in)
AC Voltage Range: 85–264 VAC
Frequency Range: 47–63 Hz

FEATURES

Displays AC Volts, Amps, Watts, and Power Factor or Hertz

Two display modes: continuous auto cycling or fixed

Universal 85-264Vac (47-63Hz) operating range (Measurement Category II)

Built-in current transformers simplify installation; choice of 10A, 32A, or 100A ranges

Ideal for power distribution units (PDUs) and power strips

True-rms readings of complex voltage and current waveforms

Low-power consumption: less than ¼watt from 120Vac

One-piece polycarbonate housing fits ‘0U’ & ‘1U’ racks

Surface mount design occupies minimal panel space

Bright red LED-display with four annunciators

Optional Frequency reading models (0.1Hz resolution)

Approvals to UL/CSA/IEC/EN 61010-1
