SIEMENS C98043-A7005-L1/6RY1704-0AA00 Pulse Transformer Board

Manager:

Yuki

Email:

sales6@askplc.com

WhatsApp:

+8617359287459

Galvanic Isolation:

Sharp Pulse Shaping:

Multi-Channel Distribution:

Conformal Surface Protection:

Utilizes magnetic pulse transformers to isolate sensitive, low-voltage control microprocessors from high-voltage main AC/DC power circuits.

Functions to clean, square, and amplify gating signals to prevent destructive misfiring or partial conduction in the power thyristors.

Configured to simultaneously handle 6-pulse or 12-pulse commutation layouts depending on the exact drive stack architecture.

Features a factory-applied protective coating to safeguard the board against conductive carbon dust, humidity, and corrosive fumes common in heavy industrial plants.
