Brief description |
The 6SL3210-1PE21-4UL0is a power module from the Siemens SINAMICS PM240-2 series. It is typically used as a core hardware component of the Siemens SINAMICS G120 frequency converter system to drive three-phase AC asynchronous motors.
|
Technical parameters |
|
|
Dimension |
10 × 29.2 × 16.5 cm |
|
Weight |
2.90 kg |
|
Input Phase Number |
3 AC |
|
Line Voltage |
380 ... 480 V ±10% |
|
Line Frequency |
47 ... 63 Hz |
|
Rated Current (LO) |
17.20 A |
|
Rated Current (HO) |
15.30 A |
|
Output Phase Number |
3 AC |
|
Rated Voltage |
400 V IEC / 480 V NEC |
|
Rated Power (LO) |
5.50 kW / 7.50 hp |
|
Rated Power (HO) |
4.00 kW / 5.00 hp |
|
Rated Current (LO) |
13.20 A |
|
Rated Current (HO) |
10.20 A |
|
Maximum Output Current |
20.40 A |
|
Pulse Frequency |
4 kHz |
|
Output Frequency (Vector Control) |
0 ... 200 Hz |
|
Output Frequency (V/f Control) |
0 ... 550 Hz |
|
Power Factor (λ) |
0.85 |
|
Offset Factor (cos φ) |
0.95 |
|
Efficiency (η) |
0.97 |
|
Sound Pressure Level (1 m) |
72 dB |
|
Power Loss |
0.15 kW |
|
Cooling Method |
Internal air cooling |
|
Contact me for a big surprise！ |
Email: sales3@askplc.com
Mobile(WhatsApp): 86-18150117685
John Yang is 24 hours online for you
|
Trust moore--Trustworthy global supplier |
Over the years, we have grown into a trusted global supplier with operations centers in Xiamen, China and Hong Kong, China. Our business spans the globe, with most of our valued customers located in the Middle East, Europe, the UK, Asia, and the USA.
|
Application |
Machine Factories: Used for servo drive power output and motor speed control.
Textile Plants: Used for multi-axis drive systems and frequency speed control.
Food Plants: Used for precise power distribution in packaging and filling machines.
Pharmaceutical Plants: Used for power conversion in mixer and centrifuge drive systems.
Logistics Facilities: Used for inverter power drives in stackers and sorting conveyors.
|
FAQ |
Q: What is the supported input voltage range of the 6SL3210-1PE21-4UL0?
A: The input voltage range is 380 to 480 V ±10% (3-phase AC).
Q: What is the rated output power of the 6SL3210-1PE21-4UL0 in Low Overload (LO) mode?
A: The rated output power is 5.50 kW (7.50 hp).
Q: What is the maximum output frequency of the 6SL3210-1PE21-4UL0 under vector control?
A: The vector control output frequency range is 0 to 200 Hz.
Q: What is the maximum shielded motor cable length supported by the 6SL3210-1PE21-4UL0 at the motor end?
A: It supports a maximum shielded motor cable length of 50 meters (164.04 feet).
Q: What is the enclosure frame size of the 6SL3210-1PE21-4UL0?
A: The frame size is FSB.
Q: What is the maximum allowable relative humidity during operation for the 6SL3210-1PE21-4UL0?
A: The maximum relative humidity is 95% RH, and condensation is not permitted.
|
