Siemens 6ES7135-6HB00-0DA1 Analog output module

Contact info

Email:sales3@askplc.com

Mobile:86-18150117685

Website:https://www.controldcs.com/

Manager:John Yang in moore automation

Item Overview

The 6ES7135-6HB00-0DA1 from Siemens, part of the SIMATIC series, serves as a high-performance analog output module. This unit is designed with precision in mind and employs shielded cables to maintain signal integrity. It requires a supply voltage of 24 Volts DC, allowing for permissible limits between 19.2 and 28.8 Volts DC for flexible integration within various systems.

This module features two differential inputs, which enhances its capability to handle complex signals. With an allowable input voltage rating of 30 Volts, it efficiently monitors varying signal levels. The maximum input current limit is set at 50 milliamperes, while its actual input current consumption is 39 milliamperes, ensuring effective energy usage.

Performance Specifications

CiR Configuration (RUN):

Parameter assignment changeable in RUN: Yes

Calibration in RUN:

No

Rated Supply Voltage:

24 V DC

Voltage Range (Min):

19.2 V DC

Voltage Range (Max):

28.8 V DC

Reverse Polarity Protection:

Yes

Current Consumption (Typical):

45 mA (no load)

Current Consumption (Max):

90 mA (dual-channel 20 mA output)

Power Loss (Typical):

0.9 W

Number of Analog Outputs:

2

Voltage Output Short-Circuit Protection:

Yes

Max Short-Circuit Current:

45 mA

Cycle Time (All Channels, Min):

125 µs

Oversampling Supported:

Yes

Min Load Resistance (Voltage Output):

2 kΩ

Max Capacitive Load (Voltage Output):

1 µF

Max Load Resistance (Current Output):

500 Ω

Max Inductive Load (Current Output):

1 mH

Output Ripple (0–50 kHz):

±0.02%

Linearity Error:

±0.03%

Temperature Error:

±0.003%/K

Crosstalk Between Outputs (Max):

-50 dB

Repeat Accuracy at 25°C:

±0.03%

Processing & Activation Time (TWA, Min):

70 µs

Bus Cycle Time (TDP, Min):

125 µs

Operating Temperature (Horizontal):

-30°C to +60°C

Operating Temperature (Vertical):

-30°C to +50°C

Width:

15 mm

Height:

73 mm

Depth:

58 mm

Weight:

Approx. 31 g

Application Factory

Power and Energy Industry:

Used in dispatch and control systems for thermal power plants, power grid substations, and wind/solar power plants.

Oil and Chemical Bases:

Used in process control stations for oil refineries, ethylene production lines, and large-scale fine chemical plants.

Water Treatment and Environmental Protection Facilities:

Used in automated control rooms for urban pumping stations, sewage treatment plants, and municipal water supply systems.

Manufacturing and Automated Production Lines:

Widely used in automobile assembly lines, CNC machine tool processing workshops, and semiconductor wafer manufacturing plants.

Metallurgy and Mining Industry:

Used in automated monitoring of steel smelting plants, non-ferrous metal smelting lines, and large-scale mining and beneficiation facilities.

Food, Beverage, and Pharmaceutical Industry:

Used in dairy processing lines, automated bottling workshops, and pharmaceutical purification production workshops.

FAQ

Question

Answer

Q: What is the 6ES7135-6HB00-0DA1?

A: It is an Analog output module.

Q: What shipping methods are used for 6ES7135-6HB00-0DA1?

A: Major carriers like FedEx, DHL, and UPS are primarily used for worldwide delivery.

Q: How are the 6ES7135-6HB00-0DA1 packaged?

A: 6ES7135-6HB00-0DA1 packaging generally involves multiple layers of protection to ensure safe transit.

Q: How to Check Price and Availability for 6ES7135-6HB00-0DA1?

A: Please contact John Yang for sales at +86-18150117685 or request a quote.

Q: How long is the warranty period of 6ES7135-6HB00-0DA1?

A: We offer a standard one-year warranty for all new and original products.
