 Siemens 6AV3688-3ED13-0AX0 PP17 II Push Button Panel
Siemens 6AV3688-3ED13-0AX0 Siemens 6AV3688-3ED13-0AX0 Siemens 6AV3688-3ED13-0AX0 Siemens 6AV3688-3ED13-0AX0

Siemens 6AV3688-3ED13-0AX0 PP17 II Push Button Panel

hot selling

1 year warranty

Best choice and best discounts

Email me: sales6@askplc.com

  • Item NO.:

    6AV3688-3ED13-0AX0

  • Order(MOQ):

    1

  • Payment:

    T/T

  • Product Origin:

    GERMANY

  • Color:

    Brand New

  • Shipping Port:

    Xiamen

  • Lead Time：

    3-5 days
Contact Us

  • Product Detail

Specifications
The Siemens 6AV3688-3ED13-0AX0 is a SIMATIC HMI PP17 II push button panel designed for reliable local operator control and status indication in industrial automation systems. It combines 32 short-stroke keys with 32 surface LEDs, plus 16 digital inputs and 16 digital outputs, and communicates through PROFIBUS DP12.
Model6AV3688-3ED13-0AX0
TypeSIMATIC HMI PP17 II push button panel
Short-stroke Keys32
Surface LEDs32, red / yellow / green
Digital Inputs16 x 24 V DC
Digital Outputs16 x 24 V DC, grouped in 4
Communication1 x RS485, PROFIBUS DP12, up to 12 Mbit/s
Supply Voltage18-30 V DC, rated 24 V DC
Power ConsumptionApprox. 10 W
Front MaterialAluminum
Dimensions240 x 204 x 53 mm
WeightApprox. 1.13 kg
Application Industry
01
Machine & Production ControlLocal start, stop, reset and mode selection for production equipment, machine tools and process skids.
02
Operator Panels & Local HMIClear push-button operation and LED status feedback for control cabinets, packaging lines and material handling systems.
03
Retrofit & Service ReplacementA practical replacement panel for existing Siemens SIMATIC installations using PROFIBUS DP communication.
FAQ
What is the communication interface?
It uses one RS485 interface and supports PROFIBUS DP12 communication up to 12 Mbit/s.
How many inputs and outputs are available?
It provides 16 digital inputs and 16 digital outputs, with outputs arranged in groups of four.
What supply voltage does the PP17 II require?
The permissible supply range is 18-30 V DC, with a rated supply voltage of 24 V DC.
Does the panel provide visual status feedback?
Yes. It includes 32 surface LEDs with red, yellow and green color modes.
