 Ebmpapst D3G146-AH50-16 Centrifugal Fan
D3G146-AH50-16 D3G146-AH50-16 D3G146-AH50-16

Ebmpapst D3G146-AH50-16 Centrifugal Fan

hot selling

1 year warranty

Best choice and best discounts

Email me:sales6@askplc.com

  • Order(MOQ):

    1

  • Payment:

    T/T

  • Product Origin:

    GERMANY

  • Color:

    Brand New

  • Shipping Port:

    Xiamen

  • Product Origin:

    GERMANY

  • Lead Time:

    3-5 days
Contact Us

  • Product Detail

Specifications
The ebm-papst D3G146-AH50-16 is an EC centrifugal fan forward-curved, dual-intake with housing (flange). This heavy-duty dual-inlet blower features a galvanized sheet steel housing and dynamic, vibration-damped motor suspensions on both sides to drastically minimize operational acoustics. Driven by an integrated, highly advanced Electronically Commutated (EC) internal rotor motor (M3G074-cf), it provides smart variable speed control and high-pressure airflow delivery while drastically undercutting the energy consumption of standard AC variants.
Model D3G146-AH50-16
Type EC centrifugal, forward-curved, dual-intake
Nominal Voltage 200 – 277 VAC
Phase 1~ (Single-Phase)
Frequency 50 / 60 Hz
Nominal Speed 1700 RPM
Power Input 165 W
Current Consumption 1.20 A (max 1.3 A)
Max. Airflow 1125 m³/h
Control Input 0-10 VDC / PWM
Motor EC internal rotor (M3G074-cf)
Housing Galvanized sheet steel
Application Industry
01
Industrial Cooling & Drives Inverter cooling, VFDs, power electronic stacks, DCS cabinets, rectifier panels.
02
Transportation & Infrastructure Rail transit, subway, high-speed rail cabins, locomotive control, NEV charging infrastructure.
03
Air Treatment & HVAC Industrial air purification cabinets, laminar flow hoods, compact climate control, ducted heating modules.
FAQ
What control signals does the fan accept?
It accepts both 0-10 VDC analog and PWM (pulse width modulation) inputs for variable speed control.
Is this fan compatible with 60 Hz systems?
Yes, it is rated for both 50 Hz and 60 Hz operation without derating.
What is the maximum current draw?
The nominal current is 1.20 A, with a built-in current limit set at 1.3 A for protection.
Does it include a flange for duct mounting?
Yes, the housing includes a flange, making it easy to integrate into ducted systems.
Company Service
✓ Genuine Parts 100% original with full traceability
→ Fast Delivery Global shipping directly from stock
⚙ Tech Support Expert assistance available 24/7
+ Custom Solutions Tailored configurations for your project
◆ Warranty Comprehensive after-sales protection
▤ Documentation Complete technical resource library
Recommended Products

Need D3G146-AH50-16?

Contact Moore Automation for pricing, availability and technical information.

Request a Quote →
Email sales6@askplc.com
Phone / WhatsApp +86-17359287459
Address 32D units, GuoMao Building, No 388 Hubin South Road, Siming district, Xiamen, China
