 Bently Nevada 330102-16-40-50-01-05 3300 XL 8 mm Proximity Probe
330102-16-40-50-01-05 330102-16-40-50-01-05 330102-16-40-50-01-05

Bently Nevada 330102-16-40-50-01-05 3300 XL 8 mm Proximity Probe

hot selling

1 year warranty

Best choice and best discounts

Email me:sales3@askplc.com

  • Order(MOQ):

    1

  • Payment:

    T/T

  • Product Origin:

    UK

  • Color:

    Brand New

  • Shipping Port:

    Xiamen

  • Lead Time：

    3-5 Days

  • Mode of transport:

  • HS CODE:

  • Warranty:

    1 Year

  • Product Origin:

  • Lead Time:

  • Service:

Contact Us

  • Product Detail

Specifications

Bently Nevada 330102-16-40-50-01-05 is a 3/8-24 UNF threaded 3300 XL 8 mm proximity probe with armor. Its configuration specifies 1.6 in unthreaded length, 4.0 in overall case length, 5.0 m total length, standard cable with a ClickLoc connector protector, and the CSA, ATEX and IECEx approval option.

Product type
Proximity probe
Transducer system
3300 XL 8 mm
Base model
330102
Probe tip diameter
8 mm (0.31 in)
Probe thread
3/8-24 UNF
Cable armor
With armor
Unthreaded length
1.6 in
Overall case length
4.0 in
Total length
5.0 m (16.4 ft)
Connector
Miniature coaxial ClickLoc
Connector protector
Included
Cable type
Standard cable
Approval option
CSA, ATEX and IECEx
Linear range
2.0 mm (80 mils)
Recommended gap
1.27 mm (50 mils)
Scale factor
7.87 V/mm (200 mV/mil)
Probe DC resistance
8.73 ± 0.50 Ω at 5.0 m
Cable pull strength
330 N (75 lbf)

Application Industry

01
Fluid-film bearing vibrationMeasures radial shaft vibration with the complete matched transducer system.
02
Shaft position monitoringProvides a proportional voltage for static position measurement.
03
Keyphasor referenceGenerates a phase-reference pulse from an appropriate shaft target.
04
Speed measurementSupports non-contacting tachometer measurement in documented machinery applications.

FAQ

Which Proximitor length matches Bently Nevada 330102-16-40-50-01-05?
Use the five-meter system configuration because the probe itself has a five-meter integral cable.
What mounting geometry is required for Bently Nevada 330102-16-40-50-01-05?
Provide a 3/8-24 UNF threaded mounting point with clearance for the 4.0 in case and 1.6 in unthreaded section.
What radial-vibration gap is specified for Bently Nevada 330102-16-40-50-01-05?
Set approximately 1.27 mm, corresponding to about -9 Vdc under the documented test conditions.
Does Bently Nevada 330102-16-40-50-01-05 include connector protection?
Yes. The selected connector code includes a protector with the standard cable.
What must be checked before replacing Bently Nevada 330102-16-40-50-01-05?
Match the thread, physical lengths, armor, system length, connector option and approval marking, then verify the gap after installation.
