Schneider 140CPS11420C 140CPS11420 Power Supply Module

John Yang

sales3@askplc.com

86-18150117685

Brand name:

 Schneider

Model:

 140CPS11420C 140CPS11420

Product type:

 Power Supply Module

Product description:

The Schneider 140CPS11420 Power Supply Module delivers stable 5.1 V DC output with high current capability, supporting up to 20 A under summable conditions at 60 °C. It accepts a wide AC input range of 93–132 V or 170–276 V and provides built-in protection against overvoltage and overload, ensuring reliable operation under varying load conditions. The module includes a power fault alarm output and LED indication for easy status monitoring.

Product specification:

Input Voltage: 115 V (93–132 V) AC 47–63 Hz, 230 V (170–276 V) AC
Input Current: 1300 mA at 115 V, 750 mA at 230 V
Inrush Current: 19 A at 230 V, 38 A at 115 V
Rated Power in VA: 130 VA
Associated Fuse Rating: 2 A, slow-blow
Harmonic Distortion: ≤10% of fundamental rms value
Output Voltage: 5.1 V DC
Power Supply Output Current: 11 A (60 °C standalone), 20 A (60 °C summable)
Output Overvoltage Protection: Internal
Output Overload Protection: Internal
Power Dissipation: 6 + (1.5 × Iout) where Iout is in A
Alarm Output: 1 NC 6 A 220 V power supply fault
Local Signalling: 1 LED (green) for power (PWR OK)
Module Format: Standard
Resistance to Electrostatic Discharge: 4 kV contact, 8 kV air (IEC 801-2)
Resistance to Electromagnetic Fields: 10 V/m 80–2000 MHz (IEC 801-3)
Ambient Air Temperature for Operation: 0–60 °C
Ambient Air Temperature for Storage: -40–85 °C
Relative Humidity: 95% without condensation
Operating Altitude: ≤5000 m
Package Height: 4.49 cm
Package Width: 16.3 cm
Package Length: 31.08 cm
Package Weight: 785.4 g

100% full New! - Original Factory Seal !

Warranty: 12 months!

Package: Original packing with cartons.

Delivery time: Shipped in 3 days after payment
