PLC 1746-NI16I 16 Point Analog Input Module

PLC 1746-NI16I 16 Point Analog Input Module

100% Original New
1 Year Warranty
Competitive Pice
Email: sales3@askplc.com

Brand:
Other
Order(MOQ):
1
Payment:
T/T
Product Origin:
USA
Color:
Brand New
Shipping Port:
Xiamen
Lead Time：
in stock

Product Detail

Have a quick look for 1746-NI16I

Brand name:PLC

Model: 1746-NI16I

Payment: T/T

Shipping Port: Xia men

Lead Time: In stock

Delivery time: 1-3 days

Payment: T/T

John Yang: At Your Service(24/7)!
Email:	sales3@askplc.com
Mobile(WhatsApp):	86-18150117685
Hot-selling brands in my company
Foxboro / GE / Siemens / Moore / Emerson / Ovation / Bently Nevada / ABB / ICS / TRICONEX / Honeywell / Westinghouse / Epro / Yokogawa / Allen-bradley/ Schneider / HIMA / Woodhead / Woodward

Let me introduce 1746-NI16I to you

The 1746-NI16I is an Analog Input Module, with 16-bit resolution and 16 input channels. This module falls into a Voltage Category of -20 to 20 mA. Its backplane current at 5 Volts is 125 mA, while 24 Volts results in 75 mA. Its backplane power consumption is 2.425 Watts maximum (0.625 Watts at 5 Volts DC and 1.8 Watts at 24 Volts DC). The common mode voltage range of this module is +/-10.25 Volts relative to the analog common terminal.

This unit has a relative humidity of 5% to 95% without condensation. Its operating temperature range is -25 to 60 degrees Celsius (-13 to 140 degrees Fahrenheit) while its nonoperating temperature lies between -40 and 85 degrees Celsius (-40 and 185 degrees Fahrenheit). Its Input impedance is 249; its maximum voltage input is ±8 Volts between analog common and any input terminal, and the maximum current input is ±30 mA. The thermal dissipation of this module is 2.43 Watts, and the AIFM Connector of this module is 25-pin D-shell. When installing modules in the chassis, it is not necessary to remove the terminal blocks from the module. However, if the terminal block is removed, use the label located next to the terminal block to identify the location and type of module.

Analog inputs are used to interface analog process variables to measure its magnitude. It is primarily used to monitor or used as feedback signal for closed loop control systems to implement manual or automatic control with the use of control methods typically Proportional-Integral-Derivative (PID) algorithm. Without this feedback signal, automatic control cannot be fully implemented.

Learn more about 1746-NI16I
Product Line:	SLC 500
Part Number:	1746-NI16I
GTIN:	10611320228196
Weight:	0.75 lbs (0.34 kg)
Module Type:	Analog I/O Module
Backplane Current (5 V):	125 mA
Backplane Current (24 V DC):	75 mA
Inputs:	16
Electrical Signal Type:	0 to 20 mA, 4 to 20 mA, ±20 mA, 0 to 1 mA
Bandwidth:	6–250 Hz
Chassis Location:	Any I/O module slot except slot 0
Step Response:	9–630 ms
Thermal Dissipation:	2.43 W
Conversion Type:	Sigma-Delta
Applications:	Combination 120 V AC I/O
Input Filtering:	Low-pass digital filter with programmable frequencies
Input Filter Frequencies:	6, 10, 20, 40, 60, 80, 100, 250 Hz
Isolation:	500 V AC for 1 second
LED Indicators:	5 green status LEDs (one per 4 channels) plus 1 for module status
Recommended Cable:	Belden #8761 or equivalent
UPC:	10611320228196

More information of 1746-NI16I

Features
High Resolution: 16-bit resolution for accurate signal conversion.
Isolation: 500 VACand 71o v DC isolation per channel.
Diagnostic capabilities: Built-in diagnostics for monitoring and troubleshooting input status.
Flexible Configuration: Supports various input ranges and sampling rates
Environmental compliance: Adheres to RoHs standards.

Module Installation and Removal
When installing the module in a chassis, it is not necessary to remove the terminal
block from the module. However, if the terminal block is removed, use the write-on
label (shown below) located on the side of the terminal block to identify the module
location and type.

Module Installation Procedure
1. Align the circuit board of the analog input module with the card guides located at
the top and bottom of the chassis.
2. Slide the module into the chassis until both top and bottom retaining clips are
secured. Apply firm even pressure on the module to attach it to its backplane
connector. Never force the module into the slot.
3. Cover all unused slots with the Card Slot Filler, Catalog Number 1746-N2.

Module Removal Procedure
1. Press the releases at the top and bottom of the module and slide the module out
of the chassis slot.
2. Cover all unused slots with the Card Slot Filler, Catalog Number 1746-N2.

Frequently Asked Questions (FAQ)

Does the 1746-NI16I come with a warranty?
Yes, the 1746-NI16I includes a free 1-year warranty.

How many inputs does this module have?
The 1746-NI16I module has a total of 16 inputs.

What is this module’s thermal dissipation?
The 1746-NI16I has a thermal dissipation around 2.43 Watts.

Professional services we provide
Q: How fast can the products be shipped?	A: In-stock items can be shipped within 1–3 days.
Q: What kind of industry experience do you have?	A: We have over a decade of sales experience in the industry.
Q: Do you offer a wide range of products?	A: Yes, we provide an extensive inventory with multiple brands and global warehousing.
Q: How do you ensure product quality?	A: All products are verified and come with a 1-year warranty for quality assurance.

Professional Moore Company

Since 2003, Moore Automation has continuously expanded its product line and customer base. The company has repeatedly been recognized as a trusted supplier, a testament to its sustained growth and significant influence. Today, Moore Automation boasts the industry's most comprehensive selection of manufacturers and industrial automation equipment, encompassing programmable logic controllers (PLCs), human-machine interfaces (HMIs), distributed control systems (DCS), panel controllers, industrial PCs, and variable frequency drives (VFDs).

Other items in stock worth checking
