MSYSTEM R7F4DH-4-DAC16C-R NPN Transistor 8-Point Output Module

Part Number: R7F4DH-4-DAC16C-R

Input Common: Positive common (8 points/common)
Output Common: Negative common (8 points/common)
Rated Input/Load Voltage: 24V DC ±10%, ripple factor 5% p-p or less
Number of Input/Output Points: 8 input points, 8 output points
Number of Simultaneously Active I/O Points: Unlimited (at 24V DC)
Contact I/O Status Indicator: Lights up when ON (LED)
Isolation: I/O/sensor power supply - HLS - power supply - FE
Number of Occupied Stations: 1
ON Voltage/ON Current: 15V DC or greater (between I/O terminals X0 to X7 and +24V) / 3.5mA or greater
OFF Voltage/OFF Current: 5V DC or less (between I/O terminals X0 to X7 and +24V) / 1mA or less
Input Current: 5.5mA or less/point (at 24V DC)
Input Resistance: Approximately 4.4kΩ
ON Delay Time: 0.5ms or less
OFF Delay Time: 0.5ms or less
Rated Output Current: 0.1A/point, 0.8A/common
Residual Voltage: 1.2V or less
Leakage Current: 0.1mA or less
ON Delay Time: 0.2ms or less
OFF Delay Time: 0.5ms or less
Overcurrent Protection: Limits current when overcurrent is detected
Overheat Protection: Shuts off output when overheating is detected
(When connecting an inductive load (solenoid, etc.), connect a diode in parallel with the load.)

12 months warranty for all products

Original and new packing

3-5 working days shipping

High efficiency application

Good quality with long life span
