MOXA IMC-101-S-SC Ethernet-to-Fiber Media Converter

[ IMC-101-S-SC MOXA Ethernet-to-Fiber Media Converter ]

Condition: Brand New & in Stock

Service One-stop

Shipping Detail: Fedex and UPS etc

Warranty: 12 months

[ Technical Parameters ]

Ethernet Interface:10/100BaseT(X) Port (RJ45 connector) ×1
Fiber Port:100BaseFX Port (single-mode SC connector) ×1
Magnetic Isolation Protection:1.5 kV (built-in)
IP Rating:IP30
Housing:Metal
Dimensions:53.6 × 135 × 105 mm (2.11 × 5.31 × 4.13 in)
Weight:630 g (1.39 lb)
Installation:DIN-rail mounting
Input Voltage:12–45 V DC
Input Current:200 mA @ 12–45 V DC
Overload Current Protection:Supported
Power Connector:Terminal block
Power Consumption:200 mA @ 12–45 V DC
Operating Temperature:0–60°C (32–140°F)
Storage Temperature:-40–85°C (-40–185°F)
Ambient Relative Humidity:5–95% (non-condensing)
MTBF:401,000 hrs
Standard:MIL-HDBK-217F

[ Contact John Yang ]

Email → sales3@askplc.com

Mobile(WhatsApp) → 86-18150117685

[ Service ]

1. Warranty: 365 days

2.Lead time: 1-2 working days.

3.Type of payment: T/T and Western Union.

4. Courier partners: DHL, UPS, TNT, FedEx and EMS.

5.Technical specification, manuals and data sheets: Available on request.
