 Honeywell DC1010CR-101000-E DC1000 48 x 48 mm RTD Input Temperature Controller
Honeywell DC1010CR-101000-E Honeywell DC1010CR-101000-E Honeywell DC1010CR-101000-E

Honeywell DC1010CR-101000-E DC1000 48 x 48 mm RTD Input Temperature Controller

hot selling

1 year warranty

Best choice and best discounts

Email me:sales3@askplc.com

  • Order(MOQ):

    1

  • Payment:

    T/T

  • Product Origin:

    USA

  • Color:

    Brand New

  • Shipping Port:

    Xiamen

  • Lead Time：

    3-5 Days

  • Warranty:

    1 Year
Contact Us

  • Product Detail

Specifications

Honeywell DC1010CR-101000-E DC1000 48 x 48 mm RTD Input Temperature Controller is a compact DC1000-family controller identified by Honeywell with RTD input in a 48 x 48 mm, 1/16 DIN format. The platform combines fast process-value sampling, flexible control algorithms, clear LED indication and optional serial communication for industrial temperature-control panels.

Product type
Microprocessor-based temperature controller
Controller model
DC1010
Form factor
1/16 DIN
Panel dimensions
48 x 48 mm
Configured input
RTD input
Supported RTD types
Pt100, JPt100, JPt50
PV sampling time
250 ms
Remote setpoint sampling
500 ms
Input resolution
14 bit
Digital indication accuracy
±0.2% full scale
Control algorithms
PID, ON/OFF, Heat/Cool, motor position, phase angle, zero crossover
Power supply
85 to 265 V AC, 50/60 Hz; optional 24 V DC
Power consumption
8 VA at 110 V; 12 VA at 220 V
Display
Dual 4-digit 7-segment LED with 10-LED bargraph
Status indication
Up to 8 status LEDs
Memory
Non-volatile EEPROM
Communication
RS-232 or RS-485; Modbus RTU/ASCII
Controllers per host
Up to 30
Operating temperature
0 to +50 °C
Ambient temperature
-20 to +65 °C
Relative humidity
50 to 85% RH, non-condensing
Approvals
UL and CE mark

Application Industry

01
Industrial dryersMaintains repeatable process temperature in drying equipment.
02
Semiconductor packaging and testSupports temperature regulation in controlled production equipment.
03
Plastic processingProvides closed-loop control for thermal process zones.
04
Packaging and climatic equipmentApplies configurable control to packaging machinery and environmental chambers.

FAQ

Which sensor input is identified for Honeywell DC1010CR-101000-E?
The official product record identifies an RTD input configuration; confirm the installed sensor type and wiring before commissioning.
What panel opening should be prepared for Honeywell DC1010CR-101000-E?
Use the 48 x 48 mm controller format and verify the exact cutout and mounting clearances in the installation documentation.
Which control strategies can Honeywell DC1010CR-101000-E support?
The controller family provides PID, ON/OFF, heat/cool, motor-position, phase-angle and zero-crossover control options.
How should communication be planned for Honeywell DC1010CR-101000-E?
Use the configured RS-232 or RS-485 interface with Modbus RTU or ASCII, and keep the host network within the documented controller limit.
What environmental checks are required before installing Honeywell DC1010CR-101000-E?
Confirm 0 to +50 °C operating temperature and 50 to 85% non-condensing relative humidity at the panel location.
