GE IC693ALG222C Analog Input Module

hot selling

1 year warranty

Best choice and best discounts

Email me:sales6@askplc.com

Brand:
GE
Order(MOQ):
1
Payment:
T/T
Product Origin:
USA
Color:
Brand New
Shipping Port:
Xiamen
Product Origin:
USA
Lead Time:
3-5 days

Product Detail

Sale Manager:	Email:	Mobile(WhatsApp):
Yuki Huang	Sales6@askplc.com	+86-17359287459

Item Details

Model:	IC693ALG222C
Number of Channels:	1 to 16 selectable, single-ended 1 to 8 selectable, differential
Input Current Ranges:	0V to +10V (unipolar) or –10V to +10V (bipolar); selectable each channel
Calibration:	Factory calibrated to: 2.5 mV per count on 0V to +10V (unipolar) range 5 mV per count on –10 to +10V (bipolar) range
Update Rate:	6 msec (all 16 single-ended channels) 3 msec (all 8 differential channels)
Resolution at 0V to +10V:	2.5 mV (1 LSB = 2.5 mV)
Resolution at –10V to +10V:	5 mV (1 LSB = 5 mV)
Absolute Accuracy:	± 0.25% of full scale @ 25C (77F) ± 0.5% of full scale over specified operating temperature range
Linearity:	< 1 LSB
Isolation:	1500 volts between field side and logic side
Common Mode Voltage (Differential):	± 11V (bipolar range)
Cross-Channel Rejection:	> 80 db from DC to 1 kHz
Input Impedance:	>500K ohms (single-ended mode) >1M ohms (differential mode)
Input Filter Response:	41 Hz (single-ended mode) 82 Hz (differential mode)
Internal Power Consumption:	112 mA (maximum) from the backplane +5 VDC bus 41 mA (maximum) from the backplane Isolated +24 VDC supply

Features

① Flexible Channel Configuration: The module can be configured to operate as either 16 single-ended input channels or 8 differential input channels, allowing you to prioritize either maximum channel count or improved noise immunity depending on your application requirements.

② High Density per Slot: As a 16-channel module, it maximizes I/O density by allowing a single slot to monitor up to 16 analog voltage signals, which is particularly valuable in systems where backplane slots are limited.

③ Good Resolution and Accuracy: It offers 12-bit resolution resulting in 2.5 mV per count for the 0-10V range and 5 mV per count for the -10-10V range, with an absolute accuracy of ±0.25% of full scale at 25°C and linearity of less than 1 LSB.

④ 1500V Isolation Barrier: A robust 1500 Volts RMS isolation barrier exists between the field-side wiring (sensor connections) and the PLC logic-side backplane, protecting the CPU from voltage spikes, surges, and ground loops common in industrial environments.

⑤ Built-In Input Filtering: The module includes an input filter response of 41 Hz in single-ended mode and 82 Hz in differential mode, which helps smooth noisy signals and reduces the impact of high-frequency electrical interference.

⑥ High Input Impedance: The module features an input impedance of greater than 500K ohms in single-ended mode and greater than 1M ohms in differential mode, minimizing the loading effect on connected sensors and preserving signal integrity.
