Product Infor
Brand name: Bently Nevada
Model: 330186-02
Warranty period: 1 year
Condition: 100% original new
Transportation period: DHL FEDEX EMS UPS TNT
Full Details
Weight
2.8 kg (6.2 lb)
Measurement Type
Shaft micrometer / precision micrometer
Measurement Range
0–25 mm
Scale Units
Micrometer (metric units)
Probe Mounting Adapters
1/4 in, 3/8 in, 1/2 in, 5/8 in, M8, M10, M14, M16 thread sizes
Target Button Material
AISI 4140 alloy steel
Target Button Diameter
30.5 mm (1.20 in) flat target
Casing Material
ABS plastic
Size
15.2x24.6x35.6cm
Resolution
0.01 mm
Accuracy
±0.003 mm
Qiuck Details
The 3300 XL Shaft Micrometer is primarily used to check the output signal of a Proximitor Sensor when viewing the rotor shaft or a reciprocating compressor piston rod. A strap attaches to a mounting base, is wrapped around the target, and is tightened to hold the mounting base firmly in position. A spindle micrometer verifies the Proximitor Sensor output signal.
|
Ask for Quotation |
|
|
|
Contact: John Yang |
|
|
Email: sales3@askplc.com |
|
|
Mobile(WhatsApp): 86-18150117685 |
Application
Thermal power plants: Verification of turbine and generator shaft vibration sensors.
Hydropower plants: Calibration of hydro-generator main shaft displacement sensors.
Nuclear power plants: Validation of monitoring probes for reactor coolant pumps and turbine systems.
Refinery plants: Calibration of bearing sensors for hydrocracking feed pumps and centrifugal compressors.
LNG plants: Verification of shaft displacement and vibration probes for LNG compressor trains.
Careful Customer Service
Over millions spares inventory
Fast lead times deliver uptime globally
100% brand-new and original products
Competitive prices and specific dealer discounts
Frequently Asked Questions
Q: What is the measurement range for 330186-02?
A: It is 0–25 mm.
Q: What probe mounting adapter thread sizes are available for 330186-02?
A: They include 1/4 in, 3/8 in, 1/2 in, 5/8 in, M8, M10, M14, and M16 sizes.
Q: What casing material is used for 330186-02?
A: It is made of ABS plastic.
Q: What is the measurement resolution of 330186-02?
A: The resolution is 0.01 mm.
Q: What is the accuracy specification for 330186-02?
A: It is within ±0.003 mm.
