Our company's advantageous brands
Foxboro/GE/Siemens/Moore/Emerson/Ovation/BentlyNevada/ABB/ICS/TRICONEX/Honeywell/
Westinghouse/Epro/Yokogawa/Allen-bradley/ Schneider /HIMA/Woodhead/Woodward
|
Specification Highlights |
|
|
Total Length and Mounting Option |
1.0 meter (3.3 feet) system length, no mounting hardware |
|
Agency Approval Option |
CSA, ATEX, IECEx Approvals |
|
Proximitor Sensor Input |
Accepts one non-contacting 3300-series 5 mm, 3300 XL 8 mm Proximity Probe and Extension Cable |
|
Power |
-17.5 Vdc to -26 Vdc |
|
Proximitor Sensor Material |
A308 aluminum |
|
Supply Sensitivity |
Less than 2 mV change in output voltage per volt change in input voltage |
|
Output Resistance |
50 Ω |
|
Operating Temperature |
-52°C to +100°C (-62°F to +212°F) |
|
Storage Temperature |
-52°C to +105°C (-62°F to +221°F) |
|
Frequency Response |
(0 to 10 kHz), +0, -3 dB, with up to 305 meters (1000 feet) of field wiring |
|
Minimum Target Size |
15.2 mm (0.6 in) diameter (flat target) |
|
Output Voltage in Mil pp/Gauss(9 meter Proximitor Sensor) |
0.0247 (Gap 10) |
|
Output Voltage in Mil pp/Gauss(9 meter Proximitor Sensor) |
0.0323 (Gap 50) |
|
Output Voltage in Mil pp/Gauss(9 meter Proximitor Sensor) |
0.0348 (Gap 90) |
Overview of the Product
The 3300 XL 8 mm Proximity Transducer System provides an output voltage that is directly proportional to the distance between the probe tip and the observed conductive surface and can measure both static (position) and dynamic (vibration) values. The system’s primary applications are vibration and position measurements on fluid-film bearing machines, as well as Keyphasor reference and speed measurements. The 3300 XL 8 mm system delivers the most advanced performance in our eddy current proximity transducer systems.
|
◆Best Price,Good price within limited time |
John Yang Email: sales3@askplc.com Mobile(WhatsApp): 86-18150117685 |
|
◆Fast Delivery&One Year Warranty |
|
|
◆24/7Service & Free Online Quotes |
Applicaiton
Power Plants: Used in TSI systems for turbines, generators, exciters, and large pumps/fans to prevent vibration failures.
Oil Refining Plants: Installed in control cabinets to monitor shaft vibration and displacement of critical compressors and blowers.
Coal-to-Liquid Gasification Plants: Applied to air compressors, oxygen compressors, and syngas compressors for SIL safety trips.
LNG Plants: Monitors bearings of large compressors to ensure continuous gas liquefaction operation.
Large Fertilizer Plants: Used on ammonia compressors, CO₂ compressors, and high-pressure pumps for shaft stability monitoring.
Frequently Asked Questions
Q: If installing the 330180-X1-05 MOD: 145004-17 in a dusty, high-humidity pump room, can it be directly exposed on the wall?
A: No, option 05 only supports open rail mounting (IP20). In harsh environments, it must be installed in an IP66/NEMA 4X metal protective housing.
Q: Why is it necessary to use a coaxial connector insulating boot to cover the probe input end when powering back on after replacing the 330180-X1-05 MOD: 145004-17 with an insulated boot?
A: Because the coaxial input housing is part of the signal circuit. Direct grounding contact may cause ground loop interference and unstable vibration readings.
Q: What are the stringent requirements for the target material of this customized 330180-X1-05 MOD: 145004-17 preamplifier?
A: Standard products are calibrated for AISI 4140 steel, but MOD: 145004-17 may be calibrated for special steels (such as stainless steel or alloys). Shaft material must be verified before replacement.
Q: When troubleshooting a circuit fault in 330180-X1-05 MOD: 145004-17 using a multimeter, the static voltage between VTX and COM was measured to be -23 Vdc. What does this mean?
A: This indicates output saturation (overload), usually caused by a probe open circuit or loose ClickLoc connector contact.
Q: When introducing the dynamic vibration signal output from 330180-X1-05 MOD: 145004-17 into the 3500 monitoring frame, where should the shielding wire connecting it be grounded at one end?
A: The signal cable shield must be grounded at the 3500 frame side, while the preamplifier end should be cut and insulated.
|
