ASCO E909PA16MU1 Electronic Valve Controller

Sale Manager: John Yang
Email: sales3@askplc.com

Mobile(WhatsApp):  86-18150117685

The E909PA16MU1 Electronic Valve Controller by ASCO is designed for industrial automation, controlling solenoid valves in dust collectors and automated systems. Operating at 115 V or 230 V AC and outputting 24 V DC, the E909PA16MU1 handles up to 25 W per channel with IP65-rated ABS housing. Equipped with 1 output relay and 2 volt-free digital inputs, the E909PA16MU1 supports auxiliary control and external signals. Front-facing LED indicators display valve status and active outputs, while the 3-key programming interface and 3-digit LED display enable precise pulse and interval adjustments. The E909PA16MU1 includes selectable supply/output voltage, short-circuit output protection, and additional cycle modes for post-cleaning or extended operations. Operating from –10 °C to +50 °C and storing safely between –20 °C to +85 °C, the E909PA16MU1 weighs 0.38 kg, making it compact for panel installation. This module delivers reliable valve sequencing, real-time monitoring, and programmable control, optimizing automation workflows and ensuring efficient operation of industrial solenoid systems.

Model: E909PA16MU1
Brand: ASCO
Product Type: Electronic Valve Controller / Sequencer
Standard Supply Voltage: 115V or 230V AC
Output Voltage: 24 V DC
Maximum Load Power Per Channel: 25 W
Enclosure Protection Rating: IP65
Operating Ambient Temperature: –10 °C to +50 °C
Storage Temperature Range: –20 °C to +85 °C
LED Indicators: Display valve controller status and active outputs
Shell Material: ABS (Acrylonitrile-Butadiene-Styrene), Gray
Weight: 0.38 kg
Output Relay: 1 (for group alarm or auxiliary control)
Digital Inputs: 2 (volt-free inputs for external control signals)
Programming Interface: 3 programming keys and 3-digit LED display
Adjustable Pulse/Interval Times: Programmable solenoid timing settings
Short-Circuit Output Protection: Per-output protection provided
Additional Cycle Modes: Post-cleaning or extended cycle options
Selectable Supply/Output Voltage: Adjustable via jumper settings

ESD Protection:On-board input protection networks
Overcurrent Protection:Current limiting on output drivers
Fault Indication:Diagnostic signaling to controller
