Product Brief
The 3HAC058040-001 is a robot body cable harness (Manipulator Harness, Axis 1-6) manufactured by ABB Robotics. It is primarily responsible for extending and transmitting the power and control signals output from the robot control cabinet (such as the IRC5 system) through and to all joint motors and encoder sensors of the robot's 1st to 6th axes.
Main Parameters
|
Size |
39x39x17cm |
|
Supported Axes |
Axis 1–6 |
|
Supply Voltage |
24 VDC |
|
Rated Insulation Voltage |
600 VAC / 1000 VDC |
|
Shielding |
High-density tinned copper braided overall shield, ≥85% coverage |
|
Minimum Dynamic Bending Radius |
10 × cable outer diameter |
|
Operating Temperature |
-10°C to +50°C |
|
Storage/Transportation Temperature |
-25°C to +70°C |
What Moore can do for you?
1.100% original product, 100% quality assurance and the more competitive price.
We send you a new product asking zero cent!
2.Thoughful service
Professional after-sales service.
3.Quick Shipping
We have large quantities of inventories, can ship immediately.
FAQ
Q: What signal or power transmission for how many robot axes can 3HAC058040-001 support?
A: The cable assembly supports connection for robot axes 1 to 6.
Q: What is the maximum rated DC insulation voltage withstand of 3HAC058040-001?
A: The maximum rated DC insulation voltage is 1000 VDC.
Q: What is the shielding coverage of the tinned copper braided shield in 3HAC058040-001?
A: The braided overall shielding coverage is not less than 85%.
Q: What is the minimum dynamic bending radius of 3HAC058040-001 during motion?
A: The minimum dynamic bending radius is 10 times the cable outer diameter.
Q: What is the minimum storage and transport temperature for 3HAC058040-001?
A: The minimum storage and transport temperature is -25°C.
Application
Automotive plants: connect joint power and signals for welding, painting, and assembly robots
Machinery plants: assemble internal cabling for CNC loading/unloading, grinding, and polishing robots
Electronics plants: deploy wiring for chip placement, PCB dispensing, and inspection robots
Hardware plants: connect harnesses for metal stamping, die-casting palletizing, and deburring robots
Home appliance plants: provide motion cables for refrigerator shell forming and washing machine assembly robots
|
