EcoStruxure Machine Expert Twin is a digital twin software suite dedicated to machine

and production line simulation,which is applicable to the full life cycle of the machine.The

development version software has the design ability of high degree of freedom,can directly

import the user's 3D drawings,and realize the user-defined functions and physical characteristics

through C # programming;Builder software can easily realize 3D modeling of equipment or production

line by dragging and dropping the drawing library, and connect PLC to realize simulation function.

Function:

General functions of all license types:•Virtual debugging 3D visualization and simulation•Drag and drop

3D export of model components from the directory•Remote viewing and remote access•PLC code writing

and debugging•Virtual operationtest equipment process flow, extreme operation capability and operation

scenarios•Create training and real simulation on machine operation•Check dimensions and plans•Check

equipment capacity and performance•Send 3D PDF, Video and pictures•Automatic

extraction and tracking of electromechanical objects•Customized visualization and monitoring objects.

Specific features of the license:

VISU•Application code testing of electromechanical model objects,such as Lexium MC12 or P4

robots•Application code of electromechanicalobjects such as directories includes predefined objects

of Schneider Electric (such as P4 Robot Maliborator) and some general machine objects

(such as belts (including actuators/sensors), seamless connection of virtual debugging.

Builder•Communication with PLC to simulate a real machine•Create a complete machine process based

on predefined components {18}•Use custom objects•Remote viewer,video export and 3D animation•Code

generation from 3D to IEC will be realized in the future.
