Penetration energy is becoming practical.

  • November 01, 2025
Background and Significance

In recent years, with the continuous growth in demand for renewable energy and the challenges faced by solar and wind power, such as weather dependence and intermittent output, a little-known but potentially huge technology—osmotic energy systems (also known as "salinity gradient energy" or "blue energy")—is regaining attention. This technology utilizes the salinity gradient between freshwater and seawater or high-salinity water flows to continuously and stably generate electricity through a semi-permeable membrane and pressure difference.

Unlike solar and wind power, a key advantage of osmotic energy is that it is not limited by weather or sunlight like wind or sunlight, but can operate "day and night," continuously generating power at locations where freshwater flows into the ocean or where high-salinity and low-salinity water come into contact.

Technical Mechanism Analysis

Osmotic energy systems mainly have two technical pathways:

Pressure-Retarded Osmosis (PRO): Freshwater migrates through a semi-permeable membrane to the saline (or high-concentration solution) side, increasing the pressure on that side. This pressure is used to drive turbines or similar devices to generate electricity.
Reverse Electrodialysis (RED): An ion flow is generated between brine and freshwater through a specialized cation/anion exchange membrane, and this ion flow is converted into an electric current.

In practical engineering, the performance of the semi-permeable membrane (selectivity, flux, durability) is a key factor limiting the commercialization of osmotic power generation systems.

Latest Developments

An osmotic power plant in Fukuoka, Japan, was completed and put into operation in 2025, generating approximately 880,000 kWh of electricity annually, enough to power about 220 homes. This facility is considered the second continuously operating power generation unit of its kind globally.

The French company Sweetch Energy has developed next-generation nanofilm technology, claiming in its technical report that it can increase the power density of membrane modules to a commercially viable level.

Key Technical Parameters (Illustrated)

Item
Current Typical Value/Range
Description
Membrane Power Density
≈ 1–2 W/m² (Early Prototype)
General Level in Design Phase
Global Potential Energy
1,600 TWh–1,700 TWh/year
Theoretical Estimate
Annual Power Generation (Japan Project)
≈ 0.88 GWh/year
Actual Operating Data

Technological and Engineering Advantages

Continuous and Stable Output: Unlike wind/solar power, which is affected by climate, the freshwater and brine mixture can operate stably around the clock.


Low Carbon and Environmentally Friendly: No fuel consumption, almost no greenhouse gas emissions.

Widely Distributed Potentially: Resource availability is available in multiple estuaries, coastlines, and salt lakes worldwide.

Current Challenges

High Membrane Material Cost and Low Efficiency: There is currently a trade-off between membrane selectivity and flux, resulting in a relatively low actual power density.

Energy Recovery and System Losses: Energy consumption exists in freshwater/brittle water transportation, pretreatment, membrane flux resistance, turbine efficiency, and other processes.

Environmental and Water Resource Impact Assessment: The mixing of freshwater and saltwater, and changes in salinity, may have ecological impacts, requiring scientific assessment.

Scalability and Economics: Currently, most projects are demonstration projects and have not yet achieved cost competitiveness with traditional renewable energy in large-scale deployment.

Application Prospects and Market Positioning

Infiltration energy is suitable for deployment in the following scenarios:

Estudies and areas rich in seawater-freshwater mixtures.

Next to seawater desalination plants and high-salinity wastewater treatment facilities—utilizing salinity gradients as a "source of utilization."

Complementing other renewable energy sources to provide a stable "baseload" output to the grid.

With breakthroughs in membrane technology and cost reductions, this technology is expected to gradually move from demonstration to commercialization in the next 5–10 years. Engineering companies and energy enterprises are incorporating it into their emerging energy strategies.

Summary

Infiltration energy systems represent a new "blue" renewable energy route. With its characteristics of "stability, sustainability, and wide distribution," it has the potential to become an important technology to supplement solar/wind energy. However, to achieve large-scale commercialization, breakthroughs are still needed in membrane materials, system efficiency, cost control, and environmental adaptability. The current power generation project in Fukuoka, Japan, marks the transition of this technology from theory and experiment to practical application, and deserves continued attention from the industry.
