GE IC200MDL241 Discrete Input Module: Comprehensive Technical Guide

April 18, 2025

Introduction

The GE IC200MDL241 is a high-performance discrete input module designed for industrial automation control systems. As a critical component in VersaMax I/O and control systems, the IC200MDL241 facilitates reliable signal acquisition and logic control in demanding industrial environments. This guide provides detailed technical specifications, application scenarios, and operational considerations for the IC200MDL241 module.

IC200MDL241 Product Overview

The GE IC200MDL241 is a 16-channel discrete input module supporting 240V AC input signals. Engineered for industrial automation applications, the IC200MDL241 is compatible with VersaMax I/O carriers and features LED status indicators for enhanced diagnostics.

Key Features of IC200MDL241

16 isolated discrete input channels (240V AC rating)

Built-in electrical isolation for noise immunity

Fast response time (≤1 scan cycle)

Channel-level LED indicators for real-time monitoring

IC200MDL241 Technical Specifications

Electrical Characteristics

Parameter Specification

Input Voltage 240V AC (50/60Hz)

Backplane Current 110mA (typical)

Input Impedance ≥10kΩ

Response Time ≤1 scan cycle

Mechanical & Environmental

Mounting: VersaMax I/O carrier (hot-swappable in supported configurations)

LED Indicators: 16 channel LEDs + 1 backplane status LED

Isolation: Channel-to-channel and channel-to-backplane isolation

IC200MDL241 Applications

The IC200MDL241 is widely used in:

Manufacturing: Limit switch monitoring, safety gate detection

Energy Systems: Breaker status monitoring, transformer alarms

Building Automation: HVAC controls, fire alarm inputs

IC200MDL241 Installation & Wiring

Typical Connection Diagram

Input Signals: Connect to dry contacts or 240V AC sources

Power Requirements: Stable 240V AC supply (proper grounding essential)

IC200MDL241 FAQs

Q1: Is the IC200MDL241 hot-swappable?

A: Hot-swap capability depends on the VersaMax carrier configuration.

Q2: What input types does the IC200MDL241 support?

A: The IC200MDL241 accepts dry contacts or 240V AC signals.

Q3: How to troubleshoot non-functional LEDs?

A: Verify input signals, power supply, and backplane communication.

Conclusion

The GE IC200MDL241 discrete input module delivers high-voltage compatibility, fast response, and robust isolation for industrial automation systems. For optimal performance, always refer to the latest IC200MDL241 documentation from GE.
